4.5.6 Manual
(1) Description
This checks I/O and operates each axis and output manually.
Output button
I/O tap
I/O display button
Manual button
(2) Button Function
NO
Button
IN
1
OUT
2
INT
3
4
5
6
7
8
9
Manual
2
OUT
INT
IN
X000
X013
X024
X002
X014
X100
X004
X015
X101
X005
X016
X102
X006
X017
X103
X007
X018
X104
X008
X019
X105
X009
X020
X106
X010
X021
X107
X011
X022
X200
X012
X023
X201
0.05mm
Display input signal.
Display output signal
Display interlock signal
Turns on/off release 1 valve.
Turns on/off release 2 valve.
Turns on/off release 3 valve.
Turns on/off suction valve.[Suction On/Suction Off]
Turns on/off chuck valve.[Chuck On/Chuck Off]
Turns on/off product grip valve.[Product Grip On/Product Grip Off]
Mold: W1
Description
NEXIA-SY Series User Manual 43
4. Operation
TRAVERSE
Product
FWD/BWD
ASNT/DSNT
ROTATION
SWIVEL
Runner
FWD/BWD
ASNT/DSNT
