4. Operation

4.8 Auto Mode

(1) Description
This show automatic operation screen..
Production
Stack / Insert
(2) Button Function
NO
Button
1
Production
2
Stac/Insert
Step
3
Operation
4
5
6
7
8
9
10
11
108 NEXIA-SY Series User Manual
Auto
Target
:
8 0 0 0
Current :
8 0 0 0
1 CYCLE:
1 5 .0
TkTime :
5 .0
1DayCount:5 7 6 0
Rel
1Ly
1R
0
C
Display Targe, Current, 1 Cycle time, Take out Time, 1 Day
Production, Touch this screen will move to Target screen.
Displays stacking and insert gripping information.
Display each Step Operation. Touch this screen will move to screen
to change position, speed, time delay during automatic operation
Start Auto Operationm
Stop Operation after finished step.
Move to Input / Output Screen
Alarm on/off selection.
Error History.
1 Cycle operation with Actual speed of Automatic
Move to step setting screen.
End and go to Mold Manager screen.
12
Mold: REZZO1
NO S T E P
1
WaitPos
2
TkPos
3
AscPos
4
RelPos
Description
Step Operation
