4.6.1 New Mold

(1) Description
This creates Mold File which has mold number and mold name.
Search mold number as blank number Automatically, and input mold name using alphabet
selection and Enter button.
(2) Button Fuction
NO
Button
1
Arrow
Move cursor in text plate
button
2
Save the text with cursor
3
Delete text and number
4
Create new mold name and move back to set up screen.
5
Cancel to creat new mold
Press and activate mold number input window in order to set up mold number
arbitrarily. Other than figure cannot be inputted on mold number input window;
inputting existing mold number displays a message "mold number already exists"
and pressing
Two Same Mold file can be created in one robots control.
NewMold
1
No
Mold
W1
02
1
2 3 4 5 6 7 8 9 0
A B C D E F G H I
K L M N O P Q R S T
U V W X Y Z
.
-
makes window disappear.
Mold: COCK
ENT
ENT
J
Description
NEXIA-SY Series User Manual 47
4. Operation
