4. Operation
InputPos
PosName
P1
1
2 3 4 5 6 7 8 9 0
A B C D E F G H I
K L M N O P Q R S T
U V W X Y Z .
(2) Button Function
NO
Button
Arrow
1
button
2
3
4
5
DlyTime
6
00 .0 Sec
Speed
7
000
Manual
8
button
9
10
(3) Example
When moving from position P0 to position P1 at 70% speed after 0.3 second delay time
62 NEXIA-SY Series User Manual
2
Mold: W1
ENT
J
-
Press arrow button to move cursor to desired text.
Input text on Cursor.
Delete text.
Create file name and move to Mold Manager file
Cancel creation.
Delay time before moving to arbitrary position. [inputted by numeric key pad]
Speed to move new location. ( Input with Keypad )
Operate robot with this button to get position.
Save current position
Close and move back to step screen.
AddPos
2
Mold: W1
Pos: P1
DlyTime
Speed
0 .3 Sec
70
Current Memory
Trvs
0.0
0.0
PFwBw
100.0
100.0
PAscDsc
0.0
0.0
Rot
OFF
OFF
Swl
OFF
OFF
RFwBw
RAscDsc
10%
Description
TRAVERSE
Product
FWD/BWD
ASNT/DSNT
ROTATION
SWIVEL
Runner
FWD/BWD
ASNT/DSNT
