Specifications
Blow off flow at 0.65 MPa feed pressure
Maximum acceleration in operating condition
Contaminants and purity classes
1Data is presented as follows : for serial number ≤ V-01351 / for serial number ≥ V-01352.
6.2.3. Center of Mass, Tool Center Point (TCP)
Products
AirPick (without suction cup)
AirPick (with 1 suction cup)
AirPick (with 2 suction cups)
AirPick (with 4 suction cups)
AirPick (without suction cup) + extra reach
bracket
AirPick (with 1 suction cup) + extra reach
bracket
AirPick (with 2 suction cups) + extra reach
bracket
AirPick (with 4 suction cups) + extra reach
bracket
Extra reach bracket (alone)
Metric Units
Center of mass (mm)
X Y Z
-0.5 -9.0 21.0
-0.5 -8.5 23.4
-0.3 -5.1 40.3
-0.2 -4.2 46.7
145.8 -4.1 27.9
147.3 -4.0 29.6
159.6 -3.0 44.7
164.6 -2.7 51.6
100.5 0 10.5
Palletizing Solution - Instruction Manual
AirPick Vacuum Gripper
Imperial Units
130 SLPM
2 g
ISO 8573-1 class 3.4.3
TCP (mm)
X Y
0.0 0.0 44.7
0.0 0.0 76.7
0.0 0.0 127.7
0.0 0.0 127.7
200.0 0.0 72.2
200.0 0.0 104.2
200.0 0.0 155.2
200.0 0.0 155.2
200 0 27.5
91
Mass (g)
Z
545
580
955
1180
1192
1227
1602
1827
647
