Warning
Make sure to follow all the safety rules and regulations of your workplace while using the Robotiq Palletizing Solution.
l
Always wear all recommended personal protective equipment in accordance with your workplace's safety standards,
l
including:
Safety glasses;
o
Hearing protection;
o
Hard hats;
o
Steel-toe boots
o
Always use proper safety precautions when working with tools that contain sharp edges, pinching surfaces, or generate
l
heat.
Always lift heavy objects with your legs, not your back. If you can not lift an object alone, ask for help or find another
l
method to move it.

3.1. Scope of Delivery

1 x AX Series Palletizing Solution base including:
l
1 x Linear axis (1500 mm stroke)
o
1 x Motor
o
1 x Linear axis Controller
o
4 x Pallet sensors
o
2 x Status lights
o
1 x Cable management system
o
6 x 1/2" - 13 concrete anchors
l
1 x Box detection sensor
l
1 x Extra reach bracket for end-of-arm tooling
l
1 x Vacuum Gripper kit (Airpick, suctions cups, brackets for 2 or 4 cups) (Optional)
l
1 x Gripper coupling kit (Optional)
l
1 x 8 mm air tube (already mounted on the column)
l
1 x Material Handling Copilot software license dongle
l
1 x Set of four (4) casters
