ROBOTIQ PALLETIZING SOLUTION AX Series Instruction Manual page 90

90
Region
North America
Australia
Asia
Europe, Asia
North America, Europe, Asia
Europe
1
Possible box dimensions. Any size larger than those listed will work.
6.2.2. AirPick Vacuum Gripper
Energy source
Gripper mass (including coupling)
Minimum Feed pressure
Maximum Feed pressure
Optimal feed pressure
Air consumption at optimal pressure
Maximum torque permissible by custom suction cup bracket
Air supply connection type
AirPick Gripper noise level
Maximum Vacuum level at optimal pressure
Dimensions (mm)
(Width x Depth)
1016 x 1219
Specifications
1
1
1
1165 x 1165
1100 x 1100
1000 x 1200
1067 x 1067
800 x 1200
Metric Units
6.5 bar / 7 bar
135.9 SLPM / 106.7 SLPM
8 mm OD Tube
Examples of box dimensions
50 x 50 x 50
210 x 210 x 140
150 x 150 x 85
50 x 50 x 50
110 x 110 x 85
50 x 50 x 50
AirPick Vacuum Gripper
Electricity and compressed air
545 g
3 bar
7 bar
95 PSI / 101.5 PSI
35.9 gpm / 28.2 gpm
150 Nm
70.5 dBa
85 % / 80%
1
(mm)
Imperial Units
1.20 lb
43.5 PSI
101.5 PSI
110 lbf-ft
5/16 in OD Tube
