6.3. Electrical Specifications

6.3.1. Linear Axis Controller
Operating supply voltage
Quiescent power (minimum
Info
These are the specifications of the Robotiq Controller, excluding the robot. The overall voltage consumption will vary
depending on the robot used.
Warning
The linear axis controller is CE marked and cCSAus certified. Any modification will void the certification.
The following diagram illustrates the basic connections of the linear axis Controller. For more information, download the electrical
package on the Robotiq support
authorities.
Parameter
power consumption)
Peak current
Fig. 6-4: Linear Axis Controller electrical specifications
website. Do not modify the wiring unless you can recertify the linear axis Controller with local
Specification
100-240 Vac
60/50 Hz
290 Wmax
205 Wrms
12.8A at 120Vac
6.4A at 240Vac
