7.2. Fasteners

Periodically ensure that the bolts are tightened all over the Solution. If necessary, tight again according to the specified torques
represented in the table below.
Designation
M6
M6
M8
M10
1/2"-13
M8
M8
M8
Motor Coupling
Location
Column-Axis interface
Linear axis carriage interface
Pallet sensors
Base - Column
Wedge anchors
Hoist ring
Robot-carriage link
Lifting bracket - Linear axis link
Coupling collar
Table 7-1: Torque Settings - Palletizing Solution
Tightening Torque
(Nm)
10.5
9.9
15.0
50.0
54.2
9.5
20.0
9.5
8.0
Palletizing Solution - Instruction Manual
97
[ft-lb]
7.7
7.3
11.1
36.9
40.0
7.0
14.8
7.0
5.9
