3.4.3. Moving and Positioning the Solution
Warning
Failure to properly secure and install the equipment can result in material damage and bodily injury. In addition, note that
the warranty will not cover material damage resulting from an installation that did not comply with the instructions found in
this manual.
Warning
The transport, lifting, and moving of the Palletizing Solution should be done by qualified and authorized personnel. Failure
to do so may result in machine damage, bodily injury or death.
Although you can assemble the solution at the place of your choice, you will need to move it to its final location afterwards. You can
use one of the two following methods to securely move the Solution:
1. Using a forklift. Pay attention to the center of gravity to prevent the equipment from tipping over. Make sure to secure and sta-
bilize the Solution before moving it.
2. Using the set of casters provided with the Solution. To install them, screw the four (4) corner bolts highlighted in the image
below to lift the Solution. Screw the four (4) casters into the base. Unscrew the corner bolts to set the solution down on its
casters.
Warning
The casters are not designed to support the weight of the whole Solution. Do not install the robot before moving the
Solution on its casters.
