8 Gateway and Gateway 4 Manual v1.2
For North American power connection, select a power supply cord that is UL Listed and
CSA Certified 3 - conductor, [18 AWG], terminated in a molded on plug cap rated 125 V, [5
A], with a minimum length of 1.5m [six feet] but no longer than 4.5m.
Special Notices for European Users:
For European connection, select a power supply cord that is internationally harmonized and
marked "<HAR>", 3 - conductor, 0,75 mm2 minimum mm2 wire, rated 300 V, with a PVC
insulated jacket. The cord must have a molded on plug cap rated 250 V, 3 A.
Interconnection Cabling:
Cables for connecting to the unit's RS232 and Ethernet Interfaces must be UL certified type
DP-1 or DP-2. (Note: when residing in non-LPS circuit)
Overcurrent Protection:
A readily accessible listed branch-circuit overcurrent protective device must be incorporated
in the building wiring for the power input as follows:
1. Rated 20 A maximum in Canada and the United States.
2. Rated 13 A maximum in the United Kingdom and EU.
3. Rated 16 A maximum in Australia and other countries.
FUSES:
Make sure that only fuses with the required rated current and of the specified type are used
for replacement. The use of repaired fuses and the short-circuiting of fuse holders must be
avoided. Whenever it is likely that the protection offered by fuses has been impaired, the
instrument must be made inoperative and be secured against any unintended operation.
AC units for Denmark, Finland, Norway, Sweden (marked on product):
• Denmark - "Unit is class I - unit to be used with an AC cord set suitable with Denmark
deviations. The cord includes an earthing conductor. The Unit is to be plugged into a wall
socket outlet which is connected to a protective earth. Socket outlets which are not
connected to earth are not to be used!"
• Finland - "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan"
• Norway - "Apparatet må tilkoples jordet stikkontakt"
• Unit is intended for connection to IT power systems for Norway only.
• Sweden - "Apparaten skall anslutas till jordat uttag."
To connect the power connection:
1. Connect the power cables to the power sockets, located on the rear panel of the device.
2. Connect the power cables to the grounded AC outlets.
WARNING: Risk of electric shock and energy hazard. Disconnecting one power supply
disconnects only one power supply module. To isolate the unit completely, disconnect all
power supplies.
CHINESE SAFETY WARNINGS:
