Codec Tieline Gateway User Manual page 120

120 Gateway and Gateway 4 Manual v1.2
Configuring a Mono or Stereo Peer-to-Peer Program: Dialing
Important Notes: Before configuring a program please note:
· A program cannot be edited in the Program Manager when loaded in the codec.
· Lock a loaded custom program
cannot be unloaded by a codec dialing in with a different program type. For example,
if a multistream program is not locked it will be unloaded by a mono or stereo call.
· Some drop-down menus and settings may be greyed out intentionally depending on
features available.
· A program can be saved at several points throughout the program wizard and use
default settings to save configuration time.
· Failover is not available with SIP.
· SmartStream PLUS redundant streaming is not available with SIP or sessionless IP.
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
· Click in the text box to name the new program.
· Click the Mix drop-down arrow to associate a custom matrix mix with the program if required.
· Select Mono/Stereo Peer-to-Peer, or if you want to use an existing program as a template,
select this option. Then click Next.
Important Note: When you decide to use an existing program as a template, the new
program inherits all the settings of the template program and you can adjust these settings
as required by continuing through the program wizard.
Some Programs displayed in the Gateway-16
or multistream program in a codec to ensure it
© Tieline Research Pty. Ltd. 2021
