Front
Interfaces
Display
Keypad
Navigation
General
Size
Dimensions
Weight
AC Power
Operating
Temperature
Humidity Operating
Range
* Future Release
© Tieline Research Pty. Ltd. 2021
Panel
24-bit Color LCD Screen (480 x 128 pixels)
26 button silicon keypad
5 navigation and selection buttons
1U x 19" Rackmount
19" x 1 3/4" x 11 13/16" [482mm (W) x 44.45mm (H) x 300mm (D)]
excluding rear connectors
8 lb 13.1 oz / 4 Kg
Dual AC 90-240V IEC power inlets; 2A 50-60 Hz
0°C to 45°C (32°F to 113°F)
Gateway and Gateway 4 Manual v1.2
289
