23 Using the HTML5 Toolbox Web-GUI
The following sections provide an overview of the different configuration panels available within the
codec's HTML5 Toolbox Web-GUI. Navigate with the mouse pointer to the Menu bar at the top of
the Web-GUI screen and click to select and open each panel in turn.
When you first open the HTML5 Toolbox Web-GUI the Program Manager panel, Connections
panel and PPMs panel are loaded by default. If you retain cookies in your browser, any panels
opened previously in the Web-GUI are automatically populated when logging in subsequently. The
default panel view is displayed on login if cookies have been cleared.
The green Online indication in the top left-hand corner of the Toolbox Web-GUI indicates it is online
and can be used for codec control. A red Offline indication is displayed when the codec is
unavailable. The Upgrade symbol is displayed when a new firmware version is available for the
codec. Open the Firmware panel in the Settings menu to upgrade the codec with new firmware.
Important Note: The AoIP menu and associated panels are for managing AES67/ST2110-
30 AoIP streaming. Please see the AoIP Streaming Manual for configuration and streaming
information.
Features in Gateway and Gateway 4
Codec capabilities such as inputs, outputs and control port capabilities vary between different
models. The following table outlines major feature differences between the most popular codec
configurations available.
Product
Gateway 4
Gateway 4
Gateway 4
Gateway 4
Gateway 4
Gateway 4
Gateway
8/16
Gateway
8/16
Gateway
8/16
Gateway
8/16
Gateway
8/16
Gateway
8/16
© Tieline Research Pty. Ltd. 2021
HTML GUI Menu Bar for Opening Panels
Feature Notification
PPM Meters 8 PPMs on
encoders/decoders
Inputs 4 Channels in/out
Inputs Inputs 1-4 can be configured as analog or digital inputs (AES3 or
AES67) in pairs

Web-GUI

4 inputs and PPMs displayed
Inputs panel
Control Port Supports 8 control port inputs and 8 opto-isolated outputs via a
GPIOs single DB25 CONTROL PORT I/O connectors
Software LIOs 3 virtual inputs, 56 logical outputs, and 64 WheatNet Logic
Inputs/Outputs
PPM Meters 16
inputs/outputs/encoders/decoders
Inputs 8-16
purchased)
Inputs Inputs 1-8 can be configured as analog or digital inputs (AES3 or
AES67) in pairs
Web-GUI 8 - 16 inputs and PPMs displayed (depending on codec
Inputs panel configuration purchased)
Control Port Supports 16 control port inputs and 16 opto-isolated outputs via
GPIOs dual DB25 CONTROL PORT I/O connectors
Software LIOs 3 virtual inputs, 48 logical outputs, and 64 WheatNet Logic
Inputs/Outputs
Gateway and Gateway 4 Manual v1.2
front panel
PPMs on front
Channels In/Out (depending
display 4 inputs/outputs
panel can
on codec
67
or 4
display
configuration
