Ethernet, Wi-Fi and VLAN Configuration Options
The codec features two physical Ethernet port interfaces and up to four additional VLAN interfaces.
The codec also supports a Wi-Fi* connection via the USB port on the front panel.
VLAN interfaces have features similar to physical Ethernet interfaces. However, your network
administrator will need to configure VLAN support throughout your network for VLANs to be
supported in your codec. As an example, if only one physical Ethernet interface is available, Wi-Fi
or VLANs can be used to operate SmartStream PLUS, or to separate codec Control and Streaming
functions if required.
A range of options which can be viewed and configured via Settings > Transports > LAN1 / LAN2.
After completing configuration press the Return
dialog and press the
* WiFi modem support not included in the first firmware release.
Configure an IPv4 DHCP Address
By default the codec is programmed for DHCP-assigned IP addresses. DHCP IP addresses are
automatically assigned and can change each time you connect to an Internet Service Provider or a
router on a local area network (LAN).
1. Press the SETTINGS
2. Select Transports and press the
3. Use the down
4. Select Configuration and then Usage and then the appropriate control and/or streaming
mode for the connection. Next, press the
© Tieline Research Pty. Ltd. 2021
button to confirm the new settings..
button.
button.
navigation button to select LAN1, LAN2 or a VLAN interface.
Gateway and Gateway 4 Manual v1.2
button, then select Save in the confirmation
button.
