· Ensure you configure the serial port baud rate to match the setting of the external device
to which you are connecting. Ideally the settings on both codecs should match, or there
may be data overflow issues.
· Only the dialing codec needs to be configured to send RS232 data. Session data sent
from the dialing codec will configure all other compatible codecs (non-G3) when you
connect.
· RS232 data can be sent from the dialing codec to all endpoints of a multi-unicast or
multicast connection if a codec is capable of these connections. Note: Bidirectional
RS232 data is only available on the first connection dialed when multi-unicasting.
23.36

Creating Rules

Product
Gateway 4
Gateway
8/16
Codec 'rules' configure events based on specific codec actions. A range of default rules are
preprogrammed into the codec to facilitate activation of the most common events required by
broadcast engineers. Typically rules are based on a change in the state of a physical CONTROL
PORT GPIO, or a logic IO, or a codec program being connected or disconnected. The Gateway 4
codec has 8 hardware GPIOs and 56 logical outputs, and the Gateway 8/16 has 16 hardware
GPIOs and 48 logical outputs; both codecs also have 3 virtual inputs, and 64 WheatNet Logic
Inputs/Outputs. WheatNet logic I/Os allow Tieline WheatNet-IP enabled codecs to activate
functions across a WheatNet-IP network.
Gateway 4 GPIOs
GPI
8 (1-8)
3 (9-11)
64
Gateway 8/16 GPIOs
GPI
16 (1-16)
3 (17-19)
64
Note: WheatNet logic inputs are only available if the codec has a WheatNet-IP card installed.
There are three categories of rules:
Feature Notification
Control Port Supports 8 control port inputs and 8 opto-isolated outputs via a
GPIOs single DB25 CONTROL PORT I/O connectors
Software LIOs 3 virtual inputs, 56 logical outputs, and 64 WheatNet Logic
Inputs/Outputs
Control Port Supports 16 control port inputs and 16 opto-isolated outputs via
GPIOs dual DB25 CONTROL PORT I/O connectors
Software LIOs 3 virtual inputs, 48 logical outputs, and 64 WheatNet Logic
Inputs/Outputs
Gateway 4 Input
Physical hardware inputs
Virtual input
WNET Logic input
Gateway 8/16 Input
Physical hardware inputs
Virtual input
WNET Logic input
GPO Gateway 4 Output
8 (1-8) Physical hardware outputs
56 (9-64) Logical outputs
64 WNET Logic output
GPO Gateway 8/16 Output
16 (1-16) Physical hardware outputs
48 (17-64) Logical outputs
64 WNET Logic output
