over each link you can connect and stream audio over each interface separately and look
at the jitter reading displayed on the Connection Statistics screen.
· Use a dotted quad IPv4 address when configuring the Fuse-IP Server Address.
23.6

Line Hunt Call Answering

The codec supports line hunt call answering, whereby you can create line hunt groups for multiple
incoming callers on a first come, first served basis. This is ideal for separating groups of inputs and
outputs between different studios or stations.
As an example, when creating a program which supports connecting sixteen mono audio streams,
select Line Hunt as the routing type. Then select Group 1 for the first eight audio streams, to
route outgoing and incoming calls via inputs and outputs 1 to 8. These inputs and outputs on the
codec can be routed to a particular studio or station.
For the next eight audio streams, select Group 2 to route outgoing and incoming calls via inputs
and outputs 9 to 16. These inputs and outputs on the codec can be routed to a different studio or
station.
In a 16 stream answering program example, when Any Group is selected for all streams in Line
Hunt mode, the codec will route all incoming calls on a first come, first served basis. The dialer
doesn't have to specify a line hunt group, however they do need to select Line Hunt mode in the
dialing program for this to function correctly.
Incoming Caller ID
Tieline codecs also support incoming caller IDs, so you can uniquely identify codecs or Report-IT
users when they call in. This is particularly useful for identifying inbound callers when using line hunt
answering mode.
