22 Connecting to the ToolBox Web-GUI
There are two graphical user interface (GUI) options for configuring and connecting Tieline G5 and
G6 codecs:
1. HTML5 Toolbox Web-GUI: fully configure codec settings, create dialing programs and dial,
hangup and monitor connections.
2. HTML5 Toolbox Quick Connect Web-GUI: designed for dialing and managing simple peer-to-
peer connections; ideal for non-technical users.
About the HTML5 Toolbox Web-GUI
The HTML5 Toolbox Web-GUI improves the user experience with codec command and control and
runs seamlessly on modern browsers. The HTML5 Toolbox Web-GUI will run on Mac, Windows and
Linux computers.
About the HTML5 Toolbox Quick Connect
The HTML5 Toolbox Quick Connect Web-GUI has a reduced feature-set and allows non-technical
users to load existing programs and dial simple peer-to-peer connections with the Quick Connect
panel. To enable the Quick Connect panel press the SETTINGS
Options > WebGUI > Quick Connect > [Enabled].
22.1 Opening the HTML5 Web-GUI & Login
1. Attach an Ethernet cable to the LAN1 port on the codec.
2. Press the SETTINGS
codec.
3. Ensure the PC used to configure the codec is connected to the same LAN.
4. Launch a web browser and type the IP address of the codec into the address bar of the browser,
e.g. http://192.168.0.xxx (the last digits are the private address details unique to your codec
over a private LAN).
5. Refresh the browser and the Web-GUI landing page will display command and control options.
© Tieline Research Pty. Ltd. 2021
Gateway and Gateway 4 Manual v1.2
button and select Unit Details to view IP address details for the
63
button and navigate to IP
