Codec Tieline Gateway User Manual page 155

Configuring Output Audio Source Options
1. Click Next to configure Output Audio Source options and automatically switch between up to 4
backup audio sources to maintain program
audio. Output Audio Source options include:
· Connection: Decoded connection audio sent from a remote codec (Note: this must be
selected as one of the configured sources).
· File Playback: Audio file playback from a supported storage medium.
2. Click the blue Plus symbol
symbol
3. Click the drop-down arrow to select an Output Audio Source option.
4. Configure silence threshold parameters for enabling a configured backup option, as well as
resume thresholds for reactivating a previous source.
5. After configuring Output Audio Source options you can:
Important Notes for File Playback:
· Ensure MP3 recordings used are not variable bit rate files.
· File playback audio is sent directly to the codec outputs and therefore IGC is not
available. When you create your MP2 or MP3 files ensure the audio levels match the
audio reference level of your codec and that peaks average at the correct levels.
· Backup file audio is only sent to the outputs of the local codec. File playback audio is
not sent to encoders and cannot be transmitted via an audio stream to another codec.
· Removing storage media while audio is playing from it will result in poor audio quality
and should be avoided. If it is removed accidentally reboot the codec to ensure failover
file playback will work in future.
· If you enter a single file name ensure you add the file extension, e.g. "test.mp3", or the
file will not play back.
· If you enter a directory name, all the files within the directory will be played back. We
recommend you save all audio files as a playlist and link to this if you want them to
© Tieline Research Pty. Ltd. 2021
to remove an Output Audio Source.
i. Click Save to save the program at this point.
ii. Click Next to configure rules options.
Gateway and Gateway 4 Manual v1.2
to add a backup Output Audio Source, or click the Minus
155
