Configure a Static IPv4 Address in Gateway and Gateway 4
Static IP addresses are fixed addresses which are recommended for studio installations. Using a
static IP address ensures remote codecs can connect reliably using the same IP address over time.
1. Press the SETTINGS
2. Select Transports and press the
3. Use the down
4. Select Configuration and then Usage and then the appropriate control and/or streaming
mode for the connection. Next, press the
5. Select IPv4 Mode and press the
6. Select Static and press the
7. Navigate to IPv4 Address and enter the IP address (using the keypad or onscreen
keyboard), then press the
8. Navigate to IPv4 Subnet and enter the Subnet Mask, then press the
9. Navigate to IPv4 Gateway and enter the Gateway details, then press the
10. Press the Return
button to confirm the new settings.
11. Check the Unit Details menu to ensure the new static IP address has been entered
correctly.
Configuring a Static Public or Private IP Address in Genie, Merlin and
Bridge-IT (v.2.x firmware) Codecs
1. Press the SETTINGS
2. Select Network and press the
3. Use the down
4. Select Config and then Usage and then the appropriate control and/or streaming mode for
the connection. Next, press the
5. Select IPv4 Mode and press the
6. Select Static and press the
7. Navigate to IPv4 Static and enter the IP address, then press the
8. Navigate to IPv4 Subnet and enter the Subnet Mask, then press the
9. Navigate to IPv4 Gateway and enter the Gateway details, then press the
10. Use the up
then press the
11. Check the Unit Details menu to ensure the new static IP address has been entered
correctly.
Configuring a Static IP Address in Commander G3 and i-Mix G3 Codecs
To set up a static IP address in Commander G3 and i-Mix G3 codecs select Menu >
Configuration > Advanced > LAN settings > IP Setup > Setup > Static > IP Address >
[enter IP address] > press OK > Subnet Mask [enter Subnet Mask] > press OK > Gateway
[enter Gateway] > press OK > reboot the codec.
9120
9130
9140
9150
button.
button.
navigation button to select LAN1, LAN2 or a VLAN interface.
button.
button.
button (or select Enter using the onscreen keyboard).
button, then select Save in the confirmation dialog and press the
button.
button.
navigation button to select LAN1, LAN2, Wi-Fi or a VLAN interface.
button.
button.
button.
navigation button to scroll to the top of the menu and select Apply Setting,
button to confirm the new settings.
9121 9122
9131 9132
9141 9142
9151 9152
button.
9123
9133
9143
9153
button.
button.
button.
button.
button.
