Codec Tieline Gateway User Manual page 169

14. Click Next to configure the jitter buffer settings for the answering connection. Note: it is also
possible to configure remote jitter preferences if the remote codec supports RFC5109.
15. Click Next to configure Failure Parameters for the answering connection if required.
Please note: In most situations the default answering Failure Parameters do not need
adjustment. These settings may be useful to troubleshoot certain connections, e.g. satellite
IP links.
16. After configuring all settings there are 3 options:
Configuring Output Audio Source Options
1. Click Next to configure Output Audio Source options and automatically switch between up
to 4 backup audio sources to maintain program
audio at transmitter sites. Output Audio Source options include:
· Connection: Decoded connection audio sent from a remote codec (Note: this must be
selected as one of the configured sources).
· Input: Input audio looped to the physical codec outputs.
· HTTP: Icecast client mode to allow media server streaming from a specified URL.
· USB File Playback: Audio file playback from a USB stick.
© Tieline Research Pty. Ltd. 2021
Gateway and Gateway 4 Manual v1.2
i. If you want to create another answering connection, select the check-
box for Create another answering connection and continue
through the wizard.
ii. Click Save to save the program at this point.
iii. Click Next to configure Output Audio Source options.
169
