Statistics Panel
Feature
1 Expand/Collapse
2 New Chart button
Scheduler Panel
Feature
1 Date selection
2 Add event button
3 View type
4 Information symbol
5 Options menu
6 Close button
Description
Click to show/hide audio stream statistics, including packet arrival
data info.
Click the New Chart button to select a Data Series and create a
customized Statistics panel.
Description
Select the days you wish to view in the scheduler.
Click to create a new scheduled event.
Click to select the timeframe or timeline view of scheduled events.
Hover over the Information symbol to view Scheduler panel
information.
Click the Options symbol
generate a PDF view, or enable/disable the scheduler.
Click to close the panel.
to view timezone options and
