use. If you are only using one Ethernet port, always use LAN1. LED indications allow identification
of LAN speeds as follows:
· 1000 Mbps: Green = Blinking / Orange = Off
· 100 Mbps: Green = Off / Orange = Blinking
· 10Mbps: Green = Blinking / Orange = Blinking
USB Host Port
Rear panel USB 3.0 host port supports record and playback of audio files.
DB-9 RS-232 Port
A nine pin female RS-232 serial connection for local and remote control of equipment at either end of
the link.
© Tieline Research Pty. Ltd. 2021
Gateway and Gateway 4 Manual v1.2
27
