Codec Tieline Gateway User Manual page 130

130 Gateway and Gateway 4 Manual v1.2
5. After configuring Output Audio Source options you can:
i. Click Save to save the program at this point.
ii. Click Next to configure rules options.
Important Notes for File Playback:
· Ensure MP3 recordings used are not variable bit rate files.
· File playback audio is sent directly to the codec outputs and therefore IGC is not
available. When you create your MP2 or MP3 files ensure the audio levels match the
audio reference level of your codec and that peaks average at the correct levels.
· USB backup audio is only sent to the outputs of the local codec to which a USB stick is
attached. USB file audio is not sent to encoders and cannot be transmitted via an audio
stream to another codec.
· The USB stick can be inserted or removed at any time as long as the codec is not
already playing audio in failover mode. Removing the USB stick while audio is playing
from it will result in poor audio quality and should be avoided. If it is removed accidentally
you must reboot the codec to ensure USB failover will work reliably in future.
· If you enter a single file name ensure you add the file extension, e.g. "test.mp3", or the
file will not play back.
· If you enter a directory name, all the files within the directory will be played back. We
recommend you save all audio files as a playlist and link to this if you want them to play
out sequentially. Please note that "M3U" is the playlist file format supported by the
codec.
· File playback will occur automatically if the silence threshold parameters are breached; if
the codec is not connected for any reason file playback will commence. To stop file
playback open the Connections panel in the HTML5 Web-GUI, click to select the file
playback connection, then click Disconnect.
Configuring Rules
1. To configure new rules click the drop-down arrow and select the preferred option from those
available. Click the blue Plus symbol
to remove a rule.
to add a new rule and click the Minus symbol
© Tieline Research Pty. Ltd. 2021
