Configure Audio Options

24.4
A range of input, output, PPM, synchronization, metering and reference options are configurable
within the Audio Options menu.
1. Press the SETTINGS
2. Navigate to Audio Options and press the
PPM Mode
PPM metering can be adjusted to display inputs, outputs, encoders and decoders and can be
adjusted via Settings > Audio Options > PPM Mode. Note: Gateway 4 has 4 inputs, 4 encoders,
4 decoders, and 8 PPMs only; Gateway has 16 PPM meters and between 8 and 16 inputs
depending on configuration purchased; encoders and decoders available will match input
availability/configuration. See
AoIP Mode
All codecs support AES67 AoIP streaming. This setting selects whether the codec will stream using
either AES67 or WheatNet-IP when an optional WheatNet-IP card is installed.
1. Press the SETTINGS
2. Navigate to Audio Options and press the
3. Select AoIP Mode.
Digital Input Type
The codec supports configuration of all inputs as digital AES3, or digital AoIP inputs.
1. Press the SETTINGS
2. Navigate to Audio Options and press the
3. Select Dig. Input Type.
button.
Input Configuration, Levels and PPMs
button.
button.
button.
for more details.
button.
button.
