Codec Tieline Gateway User Manual page 69

Connect Panels: Load & Connect Programs & Manage Audio Streams
Connections Panel
Feature
1 Program
Disconnect buttons
2 Connect / Disconnect
button and Connection
State LED
3 Audio Stream Edit
4 Connection Edit button
(dialing connection)
5 TieLink
and
Connect / Disconnect
button
6 Answering
Edit button
7 Answering
Disconnect button
8 Additional Connections
9 Change Program
10 Show/Hide Arrow
© Tieline Research Pty. Ltd. 2021
Description
Connect / Click to connect or disconnect all audio streams in a program.
Click the Connect/Disconnect
all connections in an audio stream. The Connection State LED
displays status of an audio stream connection.
Click the Edit
Click the Edit
the IP address, or select a contact if a TieLink Traversal Server
contact list is configured.
Contact List Click the Connect/Disconnect
Connection an individual connection. Also adjust the connection bit-rate when
a connection is active. Click the Address Book
select a contact if a TieLink Traversal Server contact list is
configured.
connection Click to edit answering connection settings
Connection Click to disconnect an answering connection
Other connections listed
Click to unload the current program and load a new program.
Click to show/hide audio stream and connection details.
Gateway and Gateway 4 Manual v1.2
button to connect/disconnect
button to edit audio stream settings.
symbol to edit audio stream settings, including
button to connect/disconnect
69
button to
