164 Gateway and Gateway 4 Manual v1.2
o Commander G3 Rack TLR300 = Model Number TLR300
o Commander G3 Rack TLR300B = Model Number TLR350
o Commander G3 Field TLF300 = Model Number TLF300
o i-Mix G3 TLM600 = Model Number TLM600
Using Regular Expressions
To filter using regular expressions in the SIP Filter Lists panel, click the Options symbol
top right-hand corner of the panel and then click to select the Use Regular Expressions check-
box.
Important Note: Regular expressions should not use ^ and $ anchors because searches
implicitly try to match anywhere in the line.
23.18

Configure Peer-to-Peer SIP Programs

SIP programs are very similar to how a normal Tieline IP program is configured. The codec supports
dialing over SIP using a registered SIP server account, or peer-to-peer using one of the two SIP
interfaces SIP1 and SIP 2. It is also necessary to select SIP as the Session Protocol.
To configure a SIP multiple stream program simply create a new program and configure each SIP
audio stream like a single SIP Peer-to-Peer program. The codec is capable of registering up to 16
SIP accounts, each of which has an associated Answer Route field, which can be matched to a
loaded answering program's audio stream Answer Route. Without using SIP accounts, each SIP
interface also has an Answer Route field. However, only 2 SIP interfaces are supported, limiting
this method of routing configuration to a maximum of 2 audio streams. Note: An account's Answer
Route setting is applied first.
Important Notes: Before commencing program configuration please note:
· You cannot edit a program when it is currently loaded in the codec.
· Some drop-down menus and settings may be greyed out intentionally depending on
· Failover is not available with SIP and SmartStream PLUS redundant streaming is not
·
· Ensure the appropriate TCP and UDP audio ports are open in your firewall to allow SIP
1. Open the HTML5 Toolbox Web-GUI and click Connect in the Menu Bar, then select Program
Manager to launch the Program Manager panel.
2. Click the New Program button to open the wizard and:
· Click in the text box to name the new program.
· Click the Mix drop-down arrow to associate a custom matrix mix with the program if required.
· Select Mono/Stereo Peer-to-Peer, or if you want to use an existing program as a template,
select this option. Then click Next.
features available.
available with SIP or sessionless IP.
Lock a loaded custom program
be unloaded by a codec dialing in with a different type of program. For example, if a
multistream program is not locked it will be unloaded by a mono or stereo call.
audio streams to connect. See
or multistream program in a codec to ensure it cannot
Installing the Codec at the Studio for more information.
© Tieline Research Pty. Ltd. 2021
