Inputs Panel
Feature
1 Settings button
2 EQ button
3 Compressor button
4 On/Off button
5 Input Sliders/Faders
6 Input PPM meter
7 Input gain adjustment
8 Close button
© Tieline Research Pty. Ltd. 2021
Gateway and Gateway 4 Manual v1.2
Description
Click to adjust input Name, Type, Polarity Inverted and
IGC settings
Click to enable and adjust 10 band EQ settings for individual
inputs
Click to enable the input compressor on each input
Click to toggle an input on or off
Input gain control sliders/faders. Adjust input gain in +/-
0.5dB increments
Input PPM meter
Enter a dB value to adjust input gain in 0.5dB increments
Click to close the panel
