Configuring Alarm Dissemination Severity Alerts
Codec alarms can be configured for three different severity levels:
1. Click to select an alarm from those displayed in the Configure alarms panel.
2. Click Edit to configure alarm settings.
3. Click the Alarm Severity drop-down menu and select the preferred severity level.
4. Click Save to store the new settings for the selected alarm.
Configuring Alarm Dissemination Severity Alerts
Alerts for each alarm severity level are configured using the Alarm Dissemination panel.
1. Open the HTML5 Toolbox Web-GUI and click Alarms, then click Alarm Dissemination to
open the panel.
2. Click Edit to configure notification settings.
3. Select and configure relay, SNMP trap and alarm display settings for each Alarm Severity
level. Enter SNMP Trap IP Addresses as required at the bottom of the panel.
4. Click Save to store the new settings.
