WARNING:
Except for USB ports, other interfaces have to be installed while the robot is powered off. Do
not install while the robot is on to avoid abnormal shutdown.
Note that the robot connector cable does not go through the space between the legs and
4.
the brackets. Simply plug this cable as the shown in the diagram.
Make sure all the cables are firmly plugged. Also ensure the cables align the notch of the
5.
connectors.
TM Palletizing Operator User's Manual
Figure 44: Proper connections for robot connector cable
Product Version: 1.1 Document Version: 1.2
87
