Pin Signal
1 F_24V
2 EXO1_00
3 EXO1_01
4 EXO1_02
5 PE
Be noted that this connection must be under NPN sink-input type for DIO.
Users should complete the SYSLIGHT connection by themselves.

Connect Power Supply to TM Palletizing Operator

1. Before establishing the AC power connections, refer to the table below regarding the AC input
specifications of the TM Palletizing Operator.
External AC fuse (100V – 120V)
External AC fuse (220V – 240V)
IMPORTANT:
1.
2.
2. Confirm if your primary AC power supply meets the AC Input Specifications of TM Palletizing
TM Palletizing Operator User's Manual
Figure 69: SYSLIGHT Connection
Parameter
Input voltage
Input frequency
Table 20: AC Input Specifications of TM Palletizing Operator
The robot will automatically limit the total output if an AC 100V-199V power input is
used.
It is strongly recommended that the following steps are performed by skilled and
trained professionals.
Product Version: 1.1 Document Version: 1.2
Min. Typical
100 -
- -
- -
43 -
Max. Unit
240 VAC
16 A
11 A
63 Hz
