4.3.18 Command 0x13 - Get Cardholder Signature (SC-S Only | SC-F Only)

This command directs the device to send the cardholder's signature data to the host.
If an error occurs, the device terminates the command and reports the error in ACKSTS of Command
0x01 - Response ACK. For a full list of error codes, see Command 0x01 - Response ACK.
If no error occurs, the device sends the cardholder's signature data to the host using Report 0x29 - Send
Big Block Data to Host with big buffer type 0x00. The signature data is a block of two-byte pairs listing
the XY coordinates of a sequence points (e.g., X1Y1X2Y2X3Y3...), where X can range from 0x00 to
0xFF and Y can range from 0x00 to 0x7F. Y can also be 0xFF, which represents a finger or stylus lift up.
For example, if the cardholder signed with an "X," the device could transmit it as 05 0A 0A 05 00
FF 0A 0A 05 05 00 FF.
Table 4-23 - Usage Table for Command 0x13
Bit 7
Byte 0 0x13
Byte 1 Reserved
