3 - Connection Types
3.1.2 About the Report Descriptor
The list of the device's available reports and their structure is sent to the host in a report descriptor,
usually just after the device is connected to the USB port. Generally the details of the report descriptor
are abstracted by the developer's HID API; however, should it become necessary to examine a report
descriptor byte-by-byte, a full inventory of the report descriptor for these devices is provided in Table
3-1, which also indicates whether each report is a Get type or Set type or both. The reports themselves
are fully documented in the sections that follow.
Table 3-1 - USB HID Report Descriptor
Usage Page
Usage
Collection
Report Size (8)
Logical Minimum (0)
Logical Maximum (255)
Report ID (0x01) - Get
Usage (Response ACK)
Report Count (4)
Feature (Data,Var,Abs,NWrp,Lin,Pref,NNul,Nvol,Buf)
Report ID (0x02) - Set
Usage (End Session)
Report Count (1)
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
Report ID (0x03) - Set
Usage (Request Swipe Card)
Report Count (3)
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
Report ID (0x04) - Set
Usage (Request PIN Entry)
Report Count (5)
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
Report ID (0x05) - Set
Usage (Cancel Command)
Report Count (1)
Feature (Data,Var,Abs,NWrp,Lin,Pref,Nnul,Nvol,Buf)
Report ID (0x06) - Set
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Programmer's Manual (COMMANDS)
Item
Page 20 of 247 (D998200136-31)
Value (Hex)
06 20 FF
09 01
A1 01
75 08
15 00
26 FF 00
85 01
09 01
95 04
B2 02 01
85 02
09 02
95 01
B2 02 01
85 03
09 03
95 03
B2 02 01
85 04
09 04
95 05
B2 02 01
85 05
09 05
95 01
B2 02 01
85 06
