Appendix A - Examples
7) The device sends back eight instances of Report 0x23 - Card Data Report to the host, which the
host interprets as meaning the following (Note that additional headers for Ethernet are not shown):
a) Track 1: 23 01 00 2F 0-0x2E bytes of data
b) Track 2: 23 02 00 1E 0-0x1D bytes of data
c) Track 3: 23 03 00 47 0-0x46 bytes of data
d) Encrypted Track1: 23 04 00 30 0-0x2F bytes of data
e) Encrypted Track2: 23 05 00 20 0-0x1F bytes of data
f) Encrypted Track3: 23 06 00 48 0-0x47 bytes of data
g) Encrypted MagnePrint: 23 07 00 38 0-0x37 bytes of data
h) KSN and MagnePrint Status: 23 63 00 0E 0-0x0D bytes of data
8) The device sends back another Report 0x20 - Device State Report to the host.
9) If the operation status and card status from Report 0x22 - Card Status Report sent previously are
both OK, the host issues Command 0x04 - Request PIN Entry, which expands to the following
bytes:
a) 0xC0: Ethernet packet header (Ethernet Only | 802.11 Wireless Only)
b) 0x01: Execute command in Get mode (Ethernet Only | 802.11 Wireless Only | 30-Pin Only |
Bluetooth LE Only | PCI Bluetooth LE Only | RS-232 Only)
c) 0x04: Command ID (0x04=Command 0x04 - Request PIN Entry)
d) 0x1E: Wait time for PIN entry (0x1E=30 seconds)
e) 0x00: PIN mode (0x00=Enter PIN)
f) 0x44: Max and min length of PIN (in this example, PIN must be exactly four characters)
g) 0x01: Prompt tone (0x01=One beep)
h) 0x01: PIN option (0x01=ISO3)
i) 0xC0: Ethernet packet terminator (Ethernet Only | 802.11 Wireless Only)
Sample Command 0x04 (Hex)
04 1E 00 44 01 01
C0 01 04 1E 00 44 01 01 C0
01 04 1E 00 44 01 01
10) The device sends the host Command 0x01 - Response ACK if the command is successful.
11) The device sends the host Report 0x24 - PIN Response Report if PIN entry is successful.
12) The device sends the host another Report 0x20 - Device State Report.
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Programmer's Manual (COMMANDS)
USB format of command
802.11 and Ethernet format of command
iOS format of command (Note MSB order)
