4 - Command Set
Bit 7
Byte 2 0 0
Beeper Behavior (Only changes device behavior if Beeper Mode = Enabled in
Byte 3 Command 0x09 - Set / Get Device Configuration). See Table 4-101 - Beeper Behavior
Codes on page 163 for possible values.
The track data sent by the device for manually entered card data may be masked according to the device's
configuration (the same as it is for credit/debit cards), but the data shown in the following examples is
unmasked just to show the detail. The account number or QwickCode is denoted by a string of 5s, the
expiration date (or PAN4) by 3s and the CVC by 4s. The location marked by '6' indicates the field
options used when the data was collected; unused fields are 0s. 0s below denote fixed-length filler.
Track 1 card type ('B' for credit/debit cards) is set to 'M' and the name is set to the string literal
"MANUAL ENTRY/".
Track 1 data may be found in the instance of Report 0x23 - Card Data Report that contains Data ID =
0x01. The device formats Track 1 card data as follows:
%M5555555555555555^MANUAL ENTRY/^33330000004444000006?
Track 2 data may be found in the instance of Report 0x23 - Card Data Report that contains Data ID =
0x02. The device formats Track 2 card data as follows:
;5555555555555555=33330000004444006?
The device does not change the length of the CVC (either 3 or 4 characters) entered by the cardholder.
The length of the CVC thus affects the length of the track data output by the device, and the host must
locate the CVC in the track data as follows: The CVC starting position is the byte after the 6 digits which
follow the 4-digit expiration date (or PAN4). The CVC ending position in Track 1 is the byte before the 6
digits which precede the end sentinel (?); the CVC ending position in Track 2 is the byte before the 3
digits which precede the end sentinel (?).
DynaPro Go| Handheld PIN Pad Device with MSR/Contact/Contactless | Programmer's Manual (COMMANDS)
6 5 4
0=Use PAN
min 9, max 19
0
1=Use PAN
min 14, max 21
Page 67 of 247 (D998200136-31)
3 2
1=Use
1=Use
PAN in
QwickCodes
PIN block
entry
creation
1 0
Field Options:
0 = Acct,Date,CVC
1 = Acct,Date
2 = Acct,CVC
3 = Acct
