1.
Determine if the System Service Required LEDs are lit on the front panel or the
rear I/O module.
See
"Interpreting LEDs" on page
2.
From the front of the server, check the power supply Fault LEDs to identify
which power supply needs to be replaced.
See
"Power Supply and AC Power Connector LEDs" on page
Required LED is lit on the power supply that needs to be replaced.
3.
Remove the faulty power supply.
See
"Remove a Power Supply" on page
Related Information
"Power Supply Configuration" on page 135
■
"Power Supply and AC Power Connector LEDs" on page 137
■
"Remove a Power Supply" on page 139
■
"Install a Power Supply" on page 142
■
"Verify a Power Supply" on page 144
■
Remove a Power Supply
The power supply is a hot-service component that can be replaced by a customer.
This procedure requires that you handle components that are sensitive to electrostatic
Caution -
discharge. This discharge can cause failure of server components.
1.
Locate the power supply that you want to remove.
See
"Front Panel Components" on page 14
■
server.
See
"Determine Which Power Supply Is Faulty" on page 138
■
supply.
2.
Go to the rear of the server and locate the AC power connector at the rear of the
server that supplies power to the faulty power supply.
See
"Power Supply Configuration" on page
Disconnect that power cord.
3.
27.
139.
for the locations of the power supplies in the
135.
Remove a Power Supply
137. The amber Service
to locate a faulty power
Servicing Power Supplies
139
