Install a PCIe Card
3.
Insert the PCIe card into the PCIe card carrier until the bottom connector is
firmly seated in the PCIe card carrier's connector.
Caution -
that the PCIe card's connector is fully seated in the PCIe card carrier's slot, and that the notch in
the PCIe card's rear bulkhead is seated around the PCIe carrier's alignment tab.
168
SPARC T8-4 Server Service Manual • January 2022
Do not twist or turn the PCIe card as you insert it into the PCIe card carrier. Ensure
