Chassis Subassembly Components

No. Description
1 Front I/O assembly
2 Main module
3 System controls and indicators
4 Processor modules (2)
5 Chassis
6 Rear chassis subassembly (RCSA)
7 Fan modules (5)
8 PCIe carriers (16)
9 Rear I/O module
10 Power supplies (4)
11 Hard drives (8)
Links
"Servicing the Main Module" on page 97
"Servicing the Main Module" on page 97
"Front Panel Controls and LEDs" on page 29
"Servicing Processor Modules" on page 55
"Servicing the Rear Chassis Subassembly" on page 183
"Servicing Fan Modules" on page 145
"Servicing PCIe Cards" on page 155
"Servicing the Rear I/O Module" on page 173
"Servicing Power Supplies" on page 135
"Servicing Hard Drives" on page 87
