Technical data

4.2 Individual components

4.2.1 Panels

4.2.1.1 5AP1120.0573-000

4.2.1.1.1 General information
• Panel for AP1000, PPC2100 or PPC2200
• 5.7" TFT VGA color display
• Single-touch (analog resistive)
• Control cabinet installation
4.2.1.1.2 Order data
Model number Short description
Panels
5AP1120.0573-000 Automation Panel 5.7" VGA TFT - 640 x 480 pixels (4:3) - Sin-
gle-touch (analog resistive) - Control cabinet installation - Land-
scape format - For PPC2100 / PPC2200 / link modules - Com-
patible with 5PP520.0573-00
4.2.1.1.3 Technical data
Information:
The following specified characteristic data, features and limit values are only valid for these individual
components and may differ from those of the complete system. The data specified for the complete
system applies to the complete system in which this individual component is used, for example.
Model number
Revision
General information
B&R ID code
Certifications
CE
EAC
UL
HazLoc
Display
Type
Diagonal
Colors
Resolution
Contrast
Viewing angles
Horizontal
Vertical
Backlight
Type
Brightness (dimmable)
Half-brightness time
2)
Touch screen
3)
Type
Technology
Controller
Transmittance
58
Table 3: 5AP1120.0573-000 - Order data
Direction U = 80° / Direction D = 80°
Typ. 20 to 400 cd/m²
Table 4: 5AP1120.0573-000, 5AP1120.0573-000 - Technical data
5AP1120.0573-000
D0
0xE7AA
Yes
Yes
cULus E115267
Industrial control equipment
cULus HazLoc E180196
Industrial control equipment
for hazardous locations
Class I, Division 2, Groups ABCD, T4
TFT color
5.7"
262,144
VGA, 640 x 480 pixels
850:1
Direction R = 80° / Direction L = 80°
LED
50,000 h
AMT
Analog, resistive
B&R, serial, 12-bit
81% ±3%
Automation Panel 1000 user's manual V2.00
Figure
E0
1)
800:1
Direction U = 70° / Direction D = 70°
Typ. 22.5 to 450 cd/m²
