History; Disclaimer - Atmel AT90PWM2 Manual

– In-System Programmable via SPI Port
– Internal Calibrated RC Oscillator ( 8 MHz)
– On-chip PLL for fast PWM ( 32 MHz, 64 MHz) and CPU (16 MHz)
•
Operating Voltage: 2.7V - 5.5V
•
Extended Operating Temperature:
– -40°C to +105°
Product Package
AT90PWM2
SO24
AT90PWM2B
AT90PWM3
SO32,
QFN32
AT90PWM3B

1. History

2. Disclaimer

AT90PWM2/3/2B/3B
2
12 bit PWM with
deadtime
2 x 2
3 x 2
Product Revision
AT90PWM2
First revision of parts, only for running production.
AT90PWM3
Second revision of parts, for all new developments.
The major changes are :
• complement the PSCOUT01, PSCOUT11, PSCOUT21 polarity in
centered mode -
Aligned Mode" on page 139.
• Add the PSC software triggering capture -
Register – PICR0H and PICR0L" on page 170.
AT90PWM2B
• Add bits to read the PSC output activity -
AT90PWM3B
Register – PIFR0" on page 172.
• Add some clock configurations -
AT90PWM2B/3B" on page 31.
• Change Amplifier Synchonization -
See "" on page 255.
• Correction of the Errata -
This datasheet deals with product characteristics of AT90PW2 and AT90WM3. It will be updated
as soon as characterization will be done.
Typical values contained in this datasheet are based on simulations and characterization of
other AVR microcontrollers manufactured on the same process technology. Min and Max val-
ues will be available after the device is characterized.
ADC ADC Analog
Input Diff Compar
8 1 2
11 2 3
See "PSCn0 & PSCn1 Basic Waveforms in Center
See "Errata" on page 350.
Application
One fluorescent ballast
HID ballast, fluorescent ballast,
Motor control
See "PSC 0 Input Capture
See "PSC0 Interrupt Flag
See "Device Clocking Options Select
See "Amplifier" on page 252. and
