Figure 27-22. Reset Input Threshold Voltage vs. V
2,5
2
-40 °C
1,5
25 °C
85 °C
105 °C
1
0,5
0
2 2,5
Figure 27-23. Reset Input Threshold Voltage vs. V
2,5
2
1,5
1
0,5
0
2 2,5
RESET INPUT THRESHOLD VOLTAGE vs. V
VIH, RESET PIN READ AS '1'
3 3,5 4
V (V)
CC
RESET INPUT THRESHOLD VOLTAGE vs. V
VIL, RESET PIN READ AS '0'
3 3,5 4
V (V)
CC
AT90PWM2/3/2B/3B
(VIH, Reset Pin Read As '1')
CC
CC
4,5 5
(VIL, Reset Pin Read As '0')
CC
CC
4,5 5
5,5
105 °C
85 °C
25 °C
-40 °C
5,5
