21.10.2 Amplifier 1Control and Status register – AMP1CSR
4317I–AVR–01/08
• Bit 7 – AMP0EN: Amplifier 0 Enable Bit
Set this bit to enable the Amplifier 0.
Clear this bit to disable the Amplifier 0.
Clearing this bit while a conversion is running will take effect at the end of the conversion.
Warning: Always clear AMP0TS1:0 when clearing AMP0EN.
• Bit 6– AMP0IS: Amplifier 0 Input Shunt
Set this bit to short-circuit the Amplifier 0 input.
Clear this bit to normally use the Amplifier 0.
• Bit 5, 4– AMP0G1, 0: Amplifier 0 Gain Selection Bits
These 2 bits determine the gain of the amplifier 0.
The different setting are shown in
Table 21-8. Amplifier 0 Gain Selection
AMP0G1 AMP0G0
0 0
0 1
1 0
1 1
To ensure an accurate result, after the gain value has been changed, the amplifier input needs
to have a quite stable input value during at least 4 Amplifier synchronization clock periods.
• Bit 1, 0– AMP0TS1, AMP0TS0: Amplifier 0 Trigger Source Selection Bits
In accordance with the Table 21-9, these 2 bits select the event which will generate the trigger
for the amplifier 0. This trigger source is necessary to start the conversion on the amplified
channel.
Table 21-9. AMP0 Auto Trigger Source Selection
AMP0TS1 AMP0TS0
0 0
0 1
1 0
1 1
Bit 7
AMP1EN
Read/Write R/W
Initial Value 0
• Bit 7 – AMP1EN: Amplifier 1 Enable Bit
Set this bit to enable the Amplifier 1.
Clear this bit to disable the Amplifier 1.
Clearing this bit while a conversion is running will take effect at the end of the conversion.
Warning: Always clear AMP1TS1:0 when clearing AMP1EN.
• Bit 6– AMP1IS: Amplifier 1 Input Shunt
Table 21-8.
Description
Gain 5
Gain 10
Gain 20
Gain 40
Description
Auto synchronization on ADC Clock/8
Trig on PSC0ASY
Trig on PSC1ASY
Trig on PSC2ASY
6 5 4
AMP1IS AMP1G1 AMP1G0
R/W R/W R/W
0 0 0
AT90PWM2/3/2B/3B
3 2 1
- - AMP1TS1 AMP1TS0
- - R/W
0 0 0
0
AMP1CSR
R/W
0
