16.26 PSC2 Specific Register
16.26.1
PSC 2 Output Matrix – POM2
16.26.2
PSC0 Interrupt Mask Register – PIM0
16.26.3
PSC1 Interrupt Mask Register – PIM1
4317I–AVR–01/08
Bit
7
POMV2B3
POMV2B2
Read/Write
R/W
Initial Value
0
• Bit 7 – POMV2B3: Output Matrix Output B Ramp 3
This bit gives the state of the PSCOUT21 (and/or PSCOUT23) during ramp 3
• Bit 6 – POMV2B2: Output Matrix Output B Ramp 2
This bit gives the state of the PSCOUT21 (and/or PSCOUT23) during ramp 2
• Bit 5 – POMV2B1: Output Matrix Output B Ramp 1
This bit gives the state of the PSCOUT21 (and/or PSCOUT23) during ramp 1
• Bit 4 – POMV2B0: Output Matrix Output B Ramp 0
This bit gives the state of the PSCOUT21 (and/or PSCOUT23) during ramp 0
• Bit 3 – POMV2A3: Output Matrix Output A Ramp 3
This bit gives the state of the PSCOUT20 (and/or PSCOUT22) during ramp 3
• Bit 2 – POMV2A2: Output Matrix Output A Ramp 2
This bit gives the state of the PSCOUT20 (and/or PSCOUT22) during ramp 2
• Bit 1 – POMV2A1: Output Matrix Output A Ramp 1
This bit gives the state of the PSCOUT20 (and/or PSCOUT22) during ramp 1
• Bit 0 – POMV2A0: Output Matrix Output A Ramp 0
This bit gives the state of the PSCOUT20 (and/or PSCOUT22) during ramp 0
Bit
7
-
Read/Write
R
Initial Value
0
Bit
7
-
Read/Write
R
Initial Value
0
6
5
4
POMV2B1
POMV2B0
R/W
R/W
R/W
0
0
0
6
5
4
-
PSEIE0
PEVE0B
R
R/W
R/W
0
0
0
6
5
4
-
PSEIE1
PEVE1B
R
R/W
R/W
0
0
0
AT90PWM2/3/2B/3B
3
2
1
POMV2A3
POMV2A2
POMV2A1
R/W
R/W
R/W
0
0
0
3
2
1
PEVE0A
-
-
R/W
R
R
0
0
0
3
2
1
PEVE1A
-
-
R/W
R
R
0
0
0
0
POMV2A0
POM2
R/W
0
0
PEOPE0
PIM0
R/W
0
0
PEOPE1
PIM1
R/W
0
171
