18. USART
18.1 Features
18.2 Overview
AT90PWM2/3/2B/3B
184
The Universal Synchronous and Asynchronous serial Receiver and Transmitter (USART) is a
highly flexible serial communication device. The main features are:
•
Full Duplex Operation (Independent Serial Receive and Transmit Registers)
•
Asynchronous or Synchronous Operation
•
Master or Slave Clocked Synchronous Operation
•
High Resolution Baud Rate Generator
•
Supports Serial Frames with 5, 6, 7, 8, or 9 Data Bits and 1 or 2 Stop Bits
•
Odd or Even Parity Generation and Parity Check Supported by Hardware
•
Data OverRun Detection
•
Framing Error Detection
•
Noise Filtering Includes False Start Bit Detection and Digital Low Pass Filter
•
Three Separate Interrupts on TX Complete, TX Data Register Empty and RX Complete
•
Multi-processor Communication Mode
•
Double Speed Asynchronous Communication Mode
•
USART Extended mode (EUSART) with:
– Independant bit number configuration for transmit and receive
– Supports Serial Frames with 5, 6, 7, 8, 9 or 13, 14, 15, 16, 17 Data Bits and 1 or 2 Stop Bits
– Biphase Manchester encode/decoder (for DALI Communications)
– Manchester framing error detection
– Bit ordering configuration (MSB or LSB first)
– Sleep mode exit under reception of EUSART frame
A simplified block diagram of the USART Transmitter is shown in
I/O Registers and I/O pins are shown in bold.
Figure 18-1. CPU accessible
