Atmel AT90PWM2 Manual page 171

16.26.4 PSC2 Interrupt Mask Register – PIM2
16.26.5 PSC0 Interrupt Flag Register – PIFR0
16.26.6 PSC1 Interrupt Flag Register – PIFR1
16.26.7 PSC2 Interrupt Flag Register – PIFR2
AT90PWM2/3/2B/3B
172
Bit 7
-
Read/Write R
Initial Value 0
• Bit 5 – PSEIEn : PSC n Synchro Error Interrupt Enable
When this bit is set, the PSEIn bit (if set) generate an interrupt.
• Bit 4 – PEVEnB : PSC n External Event B Interrupt Enable
When this bit is set, an external event which can generates a capture from Retrigger/Fault block
B generates also an interrupt.
• Bit 3 – PEVEnA : PSC n External Event A Interrupt Enable
When this bit is set, an external event which can generates a capture from Retrigger/Fault block
A generates also an interrupt.
• Bit 0 – PEOPEn : PSC n End Of Cycle Interrupt Enable
When this bit is set, an interrupt is generated when PSC reaches the end of the whole cycle.
Bit 7
POAC0B POAC0A
Read/Write R
Initial Value 0
Bit 7
POAC1B POAC1A
Read/Write R
Initial Value 0
Bit 7
POAC2B POAC2A
Read/Write R
Initial Value 0
• Bit 7 – POACnB : PSC n Output B Activity (not implemented on AT90PWM2/3)
This bit is set by hardware each time the output PSCOUTn1 changes from 0 to 1 or from 1 to 0.
Must be cleared by software by writing a one to its location.
This feature is useful to detect that a PSC output doesn't change due to a freezen external input
signal.
• Bit 6 – POACnA : PSC n Output A Activity (not implemented on AT90PWM2/3)
This bit is set by hardware each time the output PSCOUTn0 changes from 0 to 1 or from 1 to 0.
Must be cleared by software by writing a one to its location.
6 5 4
- PSEIE2 PEVE2B PEVE2A
R R/W R/W
0 0 0
6 5 4
PSEI0 PEV0B
R R/W R/W
0 0 0
6 5 4
PSEI1 PEV1B
R R/W R/W
0 0 0
6 5 4
PSEI2 PEV2B
R R/W R/W
0 0 0
3 2 1
- -
R/W R R
0 0 0
3 2 1
PEV0A PRN01 PRN00
R/W R R
0 0 0
3 2 1
PEV1A PRN11 PRN10
R/W R R
0 0 0
3 2 1
PEV2A PRN21 PRN20
R/W R R
0 0 0
0
PEOPE2 PIM2
R/W
0
0
PEOP2 PIFR0
R/W
0
0
PEOP1 PIFR1
R/W
0
0
PEOP2 PIFR2
R/W
0
4317I–AVR–01/08
