Using the
Dial-up network
*DGPIR
setting
command Send/
(when <cid>=1)
Not send setting
*99***1# Not set
(default setting)
Not send
Send
184*99***1# Not set
(default setting)
Not send
Send
186*99***1# Not set
(default setting)
Not send
Send
Enter "AT*DGPIR=0" to return 186 (Send)/184 (Not
send) to [Not set] (default setting).
Set [Send] for sending caller ID when using mopera U
or mopera, the DOCOMO Internet connection service.
Setting dial-up network
Set the host and TCP/IP protocol. Contact the
Internet service provider or network administrator
for more information on settings.
■ Hosts
For packet transmission, set the host (APN) in
advance. Register numbers (cid) 1 to 10 for the
host (APN) in advance, to enable using packet
transmission by specifying control numbers. Host
(APN) settings are the equivalent to a phonebook
for packet transmission on a PC. Compared to
normal phonebook entries, they appear as
follows.
In phonebook
Registered number Control numbers (cids) 1 to 10
(memory number)
Other party's name Host name (host (APN))
Other party's phone
*99***<cid>#
number
For example, when the mopera host (APN),
mopera.ne.jp, is registered for cid1, connecting
to the mopera is possible by specifying the host
number "*99***1#". Other registered cids can be
used similarly.
*99***1# : Connects to host (APN) registered
to cid1. Alternatively, connect with
just *99#.
*99***2# : Connects to host (APN) registered
to to cid2.
*99***10# : Connects to host (APN) registered
to cid10.
Send/Not send
caller ID
Send
Not send
Send
Not send
(dial-up network
184 is given
priority)
Send
(dial-up network
186 is given
priority)
In Packet transmission
setting
As the default setting, mopera.ne.jp, the APN
used to connect to mopera is registered for cid1,
and mopera.net, the APN used to connect to
mopera U is registered for cid3. When connecting
to a corporate LAN or Internet service providers
other than mopera or mopera U, register the host
(APN) using cid2 or 4 to 10 (nP. 11).
For 64K data communication, enter the access
point phone number supplied by the Internet
service provider or network administrator.
Contact the Internet service provider or network
administrator for more information on settings.
Access point phone number is "*8701" for mopera U
and "*9601" for mopera when using 64K data
communication.
When using packet transmission, enter "*99***3#" for
mopera U and "*99***1#" for mopera (default setting).
Setting a dial-up network on Windows
■
Vista
On Windows Vista, use ネットワークの接続ウィ
ザード (Network connection wizard) to set the
host (APN).
Example: Using <cid>=3 to connect to mopera U,
the DOCOMO Internet connection service
Subscription to mopera U requires a charge.
1
Click [スタート] (Start) menu b [接
続先] (Connect to).
: The connect to a network screen appears.
2
Click [接続またはネットワークをセッ
トアップします] (Set up a
connection or network).
: The connect to a network screen appears.
3
Click [ダイヤルアップ接続をセット
アップします] (Set up a dial-up
connection) b [次へ] (Next).
: When two or more modems are connected to
the PC, [どのモデムを使いますか？ ] (Which
modem do you want to use?) appears. Select
[FOMA SH02A].
: The set up a dial-up connection screen appears.
