The IN terminals are used for measurement of earth fault current.
Setpoint: Im3/ErFlCurCTs
Group
Basic settings
Range [units]
/5, /1 [A]
Related FW
3.0
Description
Nominal current of the secondary side of the current transformer connected to
the controller terminals labeled IN. The primary side is adjusted by setpoint
Im3/ErFlCurCTp.
N
OTE
The IN terminals can be used either for measurement of earth current or mains
current (mains import). See also the setpoint
N
OTE
The CT secondary nominal current is adjustable only in IG-NTC and IS-NT. The
IG-NT has the CT secondary nominal current adjusted fixedly to 5A regardless of
this setpoint.
Setpoint: VT ratio
Group
Basic Settings
Range [units]
0.1 .. 500.0 [V/V]
Related FW
3.0
Description
The setpoint is used to adjust the generator voltage transformers ratio.
N
OTE
Adjust the setpoint to the value of 1.0 if the generator voltage is connected directly
to the controller terminals, i.e. without transformers.
N
OTE
Example: if you have transformers with ratio 6000/100V adjust the setpoint to the
value of 60.0.
N
OTE
The range of the generator voltage inputs must be adjusted properly. See the
setpoint
Setpoint: Vg InpRangeSel
Group
Basic settings
Range [units]
277V, 120V [-]
Related FW
3.0
Description
This setpoint selects the range of the generator voltage terminals. The 120V
range is available only in IG-NTC and IS-NT. The IG-NT has the range adjusted
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
:
:
:
:
Vg
InpRangeSel.
I/E-Pm
meas.
93
