ComAp IG-NT Reference Manual page 310

Binary output: Bin selector 4
Related FW 3.0
Description Output is closed or opened according to the setpoint
N
OTE
The output is intended for ECU-controlled engines to switch on/off some particular
ECU function by a controller setpoint if the function can be controlled by a binary
value over the J1939 bus.
Binary output: WrongPhSeq
Related FW 3.0
Description Binary output WrongPhSeq is active when at least one of the following conditions
is fulfilled: Generator/Mains/Bus phase is inverted or wrong generator/mains/bus
phase sequence or opposed generator/mains/bus phase sequence is detected.
Binary output: User Button 1
Related FW 3.0
Description This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
button.
It is possible to lock UserButton commands in configuration to specific user level.
Buttons 1-8 and 9-16 are locked separately.
ON
OFF
ON/OFF
P
ULSE
Binary output: User Button 2
Related FW 3.0
Description This output can be specified for example on buttons on IV-5/8 or in SCADA
diagram in InteliMonitor. Its state depends on function assigned to the related
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
Pressing the button changes the state of log. binary output User
Button X to closed. When the output is closed and the button is
pressed state is not changed.
Pressing the button changes the state of log. binary output User
Button X to opened. When the output is opened and the button
is pressed state is not changed.
Pressing the button changes the state of log. binary output User
Button X to opened or closed depending on previous state (it is
changed to the opposite state).
ON Pressing the button issues log. binary output User Button X to
close for one second.
N :
OTE
Repeated pressing of button during the closed period (one
second) causes issuing another puls of length of one second to
be generated from the moment of button pushing.
Bin selector 4.
