Group: Bin inputs CU
Value: BIN
Group Bin inputs CU
Units -
Related FW 3.0
Description This is a bit array containing status of physical binary inputs of the controller. Bit0
represents BI1, bit1 represents BI2 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
N
OTE
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Group: Bin outputs CU
Value: BOUT
Group Bin outputs CU
Units -
Related FW 3.0
Description This is a bit array containing status of physical binary outputs of the controller. Bit0
represents BO1, bit1 represents BO2 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
N
OTE
Click on button with "..." to get a clear list of BI names with their corresponding
values.
Group: Log Bout
Value: LogBout 1
Group Log bout
Units -
Related FW 3.0
Description This is a bit array containing status of logical binary outputs 1-16 of the controller.
Bit0 represents LBO1, bit1 represents LBO2 etc..
N
OTE
All terminals display binary values in "human-readable" form - from left to right.
That means the bit 0 is displayed in the most left position. This is different from
common use in computer science, where binary values are displayed from right to
left.
