ComAp IG-NT Reference Manual page 168

Setpoint: LS gain
Group Sync/Load ctrl
Range [units] 0.0 .. 200.0 [%]
Related FW 3.0
Description This setpoint adjusts the gain factor (P-factor) of the load-sharing PI loop. The
integration factor (I-factor) for the load-sharing loop is adjusted by the setpoint
int.
N
OTE
See the chapter
regulation loops and their adjustment.
Setpoint: LS int
Group Sync/Load ctrl
Range [units] 0 .. 100 [%]
Related FW 3.0
Description This setpoint adjusts the relative integration factor (I-factor) of the load-sharing PI
loop. The gain factor (P-factor) for the load-sharing loop is adjusted by the
setpoint
Group: Volt/PF ctrl
Setpoint: AVRRegChar
Group Volt/PF Ctrl
Range [units] POSITIVE, NEGATIVE [-]
Related FW 3.0
Description This setpoint selects the characteristic of the AVRi output of the controller. Adjust
it according to the behavior of the remote voltage adjustment input of your AVR:
POSITIVE
NEGATIVE
N
OTE
The characteristic can be also inverted by swapping the AVRi outputs that are
connected to the AVR. However, it is recommended to use the AVRRegChar
setpoint for selection of the characteristic instead of swapping the wires.
Setpoint: Voltage gain
Group Volt/PF Ctrl
Range [units] 0.0 .. 200.0 [%]
Inteli NT MINT, SW Version 3.0, ©ComAp –May 2013
IGS-NT-MINT-3.0 Reference Guide.PDF
:
Regulation loops overview
LS gain.
Select this option if raising of the voltage on the remote voltage
adjustment input causes the generator voltage to raise.
Select this option if raising of the voltage on the remote voltage
adjustment input causes the generator voltage to lower.
:
for general information about
LS
168
